Applicable Fibers
|
SM (G.652), MM (G.651), DS (G.653), NZ/NZDS (G.655), BI (G.657), Pigtail,
Drop Cable (rubber-insulated wire)
|
Average Splice Loss
|
0.02dB (SM), 0.01dB (MM), 0.04dB (DS), 0.04dB (NZ/NZDS), 0.02dB (BI)
|
Return Loss
|
≥ 60dB
|
Quick splicing time
|
8 seconds
|
Quick heating time
|
25 seconds
|
Splicing Program
|
50 groups
|
Protection Sleeve Length
|
40mm, 45mm, 60mm
|
Operating Language
|
Chinese, English, Vietnamese, French, Portuguese, Spanish
|
Operating Conditions
|
-10~+50°C (temperature), 0~95% RH (humidity), 0~5000m (altitude)
|
Power Supply
|
AC input
|
AC adaptor: 100~240V input voltage, 50/60Hz;
|
DC input
|
12V, 5A output voltage (DC)
|
Battery
|
Inner lithium battery: 10.95V, 5.2 AH, 56.94Wh, Up to 180 times splice and heat
Optional battery: 10.8V, 6.7 AH, 72.36Wh, Up to 300 times splice and heat
|
Monitor
|
Dual cameras, 9︒0 b i-directional, 4.3 inch high-light color screen
|
Fiber Image Magnification
|
X or Y Separately 400 times or Simultaneously 300 times
|
Estimated Splice Loss
|
Available, accuracy: 0.01dB
|
Electrode life
|
5000 ARC discharges
|
Cladding diameter
|
80~150 μm
|
Coating diameter
|
100~3.000 μm
|
Tension Test
|
1.96~2.25N
|
Storage of Splice Result
|
10,000 groups of latest splice results / 100 splice images
|
Splicing Mode
|
Auto & Manual & Full Auto & Stepping
|
Optical Fiber Fixture
|
3-in-1 cutting fixture; Multipurpose 1+N fixture (for SC/LC/FC connector)
|
Terminal
|
USB for Memorizing and Updating
|
Dimensions
|
120(W)*120(D)*130(H)mm
|
Weight
|
1.4kg / 1.8kg (without / with battery pack)
|
