Wave ID information can be transmitted when used with Optical Power Meter.
Tone generation, 270HZ,330HZ,1KHZ,2KHZ
Output power can be adjustable
Output power value is shown on LCD display
Intelligent backlight control (light intensity can be adjusted properly according to ambient light, which greatly reduced power consumption)
AA alkaline and AC adapter for power supply
Low battery indication
Features
Wave ID information can be transmitted when used with Optical Power Meter.
Tone generation, 270HZ,330HZ,1KHZ,2KHZ
Output power can be adjustable
Output power value is shown on LCD display
Intelligent backlight control (light intensity can be adjusted properly according to ambient light, which greatly reduced power consumption)
AA alkaline and AC adapter for power supply
Low battery indication
Applications
Maintenance in Telecom
Maintenance CATV
Fiber Optic Lab Testing
Other Fiber Optic Measurements
Specifications
|
Model |
SR3116 |
|
Operating wavelength（nm） |
1310/1550;1310/1490/1550/1625（others specify on requests） |
|
Applicable fiber |
SM，MM |
|
Laser type |
FP-LD(others specify on requests) |
|
Output Power（dBm） |
-5~-12dBm （can be adjustable） |
|
Adjustable step size（dBm） |
＜0.5 |
|
Stability(dB，30min，20℃) |
0.15 |
|
Modulation（Hz） |
CW， 270，330，1K，2K |
|
Fiber Port |
FC/PC |
|
Alkaline Battery |
3*AA，1.5V |
|
Power Supply Adaptor(V) |
8.4 |
|
Battery Operating time(h) |
45 |
|
Operation Temperature(℃) |
-10～+60 |
|
Storage Temperature(℃) |
-25～+70 |
|
Dimension |
23.5*16*8cm |
|
weight |
0.7kg |
Standard Package
optical light source
3pcs 1.5V batteries
AC adaptor
User manual
Cotton swabs and soft carrying case
